If you have a dedicated linux pc like the Raspberry Pi for your printer with a touch display, you might also like to be able to upload files directly at the printer. With a small extension cord you can put one usb output to your printer front, where you could connect a usb flash drive. If you try this you might detect one of two problems. The stick is not mounted or every stick gets a different mounting point. What you really want is a single mounting point that we can enter in the servers folder list, so we can just select the folder from the printer front end.
In this tutorial I will show how to do this on a Raspberry Pi running Jessie. On other linux distributions it will work similar. I will mention the points to watch out for you. When we are finished, every usb stick connected will be mounted to /media/flash.
Adding the Mount/Unmount Scripts
First we need two small scripts to do the mount and unmount. It does not matter where you install them, but we will create them in the Repetier-Server storage directory.
cd /var/lib/Repetier-Server mkdir scripts cd scripts
Now we create the mount script:
sudo nano mountflash
With the following content:
#!/bin/bash if [ -b "/dev/usbmemorystick" ] then mkdir /media/flash chmod 777 /media/flash chown repetierserver /media/flash mount -o uid=repetierserver /dev/usbmemorystick /media/flash fi
As you see, we mount the drive only when the special device /dev/usbmemorystick is present. Later we will create this if a usb stick is connected. We make the drive for repetierserver accessible and mount it with this user. That way the server has read and write access if required. Next is the unmount script:
sudo nano unmountflash
With this content:
#!/bin/bash umount /media/flash rmdir /media/flash
Next we make the two scripts executable:
sudo chmod 755 mountflash unmountflash
Automounting
Now it is time to tell linux that we want the usbmemorystick and to run our two scripts at the right time. This is done with two simple udev rules.
sudo nano /etc/udev/rules.d/10-flash.rules
With this content:
KERNEL=="sda1", SUBSYSTEMS=="usb", ACTION=="add", RUN+="/var/lib/Repetier-Server/scripts/mountflash", SYMLINK+="usbmemorystick" KERNEL=="sda1", SUBSYSTEMS=="usb", ACTION=="remove", RUN+="/var/lib/Repetier-Server/scripts/unmountflash"
The thing you must be careful about is the KERNEL parameter. If you have a fixed hard drive it will most likely have the sda identifier. In that case the next drive connected gets sdb as device identifier. As the Raspberry has only a sd card, it is sda1 in this case. The RUN parameter call our two scripts. If you have chosen a different position, update the path accordingly. The SYMLINK creates our special device we use for mounting.
Recent linux versions use newer udev version where mounts are executed in a sandbox. Therefore you also need to edit the file /lib/systemd/system/udev.service
sudo nano /lib/systemd/system/udev.service
and make sure the fiel contains in section Service the line
MountFlags=shared
to tell udev to not mount into a sandbox.
All you now have to do is reboot your pc and test if it works. Add the folder in Repetier-Server only if a drive is connected or you can not browse to it.
